12mm Bore 61701-2RS Single Row Deep Groove Ball Bearing 12x18x4mm V Groove Sealed 6701-2RS

Ask Lasest Price
Brand Name :	CNBTZC or OEM
Model Number :	6701 2RS
Certification :	IATF16949:2016
Price :	Please contact us,thanks
Payment Terms :	L/C,T/T
Supply Ability :	500000pcs per month
Delivery Time :	2-4 weeks

Add to Cart

Product Details
Company Profile

12mm Bore 61701-2RS Single Row Deep Groove Ball Bearing 12x18x4mm V Groove Sealed 6701-2RS

61701 2RS 6701 2RS Deep Groove Ball Bearings12mm X 18mm X 4mm Thin Section Robot Bearings 61701-2RS 6701 -2RS

The 6701 2RS deep groove ball bearing, with dimensions of 12 mm inner diameter × 18mm outer diameter × 4mm width, is renowned for its compact size, high-speed capability, and low noise characteristics.

Bearing Number			Boundary Dimensions(mm)					Basic Load Rating(N)		Limiting Speed(rpm)		Reference(kg) Weight
			Inner Diameter	Outer Diameter	Width		Chamfer	Dynamic	Static	Grease	Oil	Reference(kg) Weight
			d	D	B	B1	r(min)	Cr	Cor	Non-contact		Wt ≈
61700	ZZ		10	15	3	4	0.1	800	390	34000	40000	0.00190
61701	ZZ	2RS	12	18	4	4	0.2	910	530	32000	38000	0.00310
61702	ZZ	2RS	15	21	4	4	0.2	850	490	28000	32000	0.00360
61703	ZZ	2RS	17	23	4	4	0.2	960	610	26000	30000	0.00400
61704	ZZ	2RS	20	27	4	4	0.2	1030	720	23000	28000	0.00590
61705	ZZ	2RS	25	32	4	4	0.2	1090	830	19000	23000	0.00700
61706	ZZ	2RS	30	37	4	4	0.2	1170	980	16000	19000	0.00830
61707	ZZ	2RS	35	44	5	5	0.3	1850	1630	14000	17000	0.01500
61708	ZZ	2RS	40	50	6	6	0.3	2519	2234	12000	15000	0.02300
61709	ZZ	2RS	45	55	6	6	0.3	2577	2401	9000	13000	0.02500
61710	ZZ	2RS	50	62	6	6	0.3	2666	2636	7000	10000	0.03400
61711	ZZ	2RS	55	68	7	7	0.3	2880	3070	5000	8000	0.05500

6701 2RS bearings 12X18X4mm Specifications & Dimensions

Universal	6701 2RS
Type	Deep Groove Ball
Inner/Outer Ring/ Ball Material	Chrome Steel
Cage Material	Steel
CageType	Punching
Precision	P0,P6
Inner Dimension d(Ø)(mm)	12
Outer Dimension D(Ø)(mm)	18
Width B (or T)(mm)	4
Lubrication	Grease
Load Direction	Radial
Specifications/Environment	Standard
Number of Raceway Ring Rows	Single Track
Size Standards	Metric Series

The 6701 2RS deep groove ball bearing is widely used across various specialized fields due to its compact size and high precision. Application areas include:

Micro Motors and Precision Instruments: Suitable for use in micro motors, instruments, and computer cooling fans due to its high-speed capability and low noise. It is also used in medical devices (such as dental drills) and laboratory equipment to support precision rotating components.
Consumer Electronics and Home Appliances: Commonly found in small electronic products like smart locks, curling irons, and remote control toys, thanks to its thin-wall design that fits space-constrained environments. This type of bearing is also widely used in the motor parts of household appliances such as air conditioners and fans.
Robotics and Automation Equipment: Utilized in robot joints and robotic arms to enable low-friction, high-precision motion control. In automated production lines, it is suitable for modules requiring stable operation, such as sensors and stepper motors.
Automotive and Industrial Machinery: Applied in automotive components like motors, transmissions, and suspension systems, meeting lightweight requirements. In industrial machinery, including small machine tools and hydraulic systems, these bearings are relied upon for their high load capacity and sealing properties.
Special Application Areas: Widely adopted in the model sector (such as RC airplanes and racing car models) due to its lightweight characteristics.
